| Power Unit & Blower | | | | | |
| Diesel Engine | 28 hp | 48 hp | 60 hp | 75 hp | 113 hp |
| Max Vacuum % (inHG) | 95% (28,5”) | 95% (28,5”) | 95% (28,5”) | 95% (28,5”) | 95% (28,5”) |
| Blower Displacement | 319 cfm (Standard)
393 or 489 cfm (Optional) | 489 cfm (Standard)
593 or 759 cfm (Optional) | 759 cfm (Standard)
800 or 900 cfm (Optional) | 932 cfm (Standard)
1094 or 1281 cfm (Optional) | 1281 cfm (Standard)
1665 or 2400 cfm (Optional) |
| Fuel Tank Capacity | 50 lt (Standard) - Higher Capacity (Optional) | | | | |
| Fuel Tank Material | PE (Standard) - Steel (Optional) - Aluminium (Optional) | | | | |
| Suction Hose | 2" or 3" | 3" or 4" | 3" or 4" | 4" or 6" or 8" | 4" or 6" or 8" |
| Cabin | Open (Standard) - Tarpaulin (Optional) - Fully enclosed Insulated Nose Reduction (Optional) - Aluminum (Optional) | | | | |
| Pump Silencer | Optional | | | | |
| Electrical System | 12v | | | | |
| Control | Control Panel (Standard) - Fully Wireless Remote Control (Optional) | | | | |
| | | | | |
| Clean Up Items | | | | | |
| Spills on land items | Clean up items including anti-static shovels, metal shovels, brooms, rakes. Oil and fuel or Hazchem absorbent pads, rolls, pillows, particulate and mini booms. | | | | |
| Spills on water items | Oil and fuel or Hazchem absorbent pads, rolls, pillows, particulate, mini booms and marine oil booms. Anchor sets with buoys and ropes. Oil Skimmer with transfer pump and power pack. | | | | |
| | | | | |
| Debris Tank | | | | | |
Tank Capacity Standard
Tank Capacity Optional | 1000 L
1250 L - 4000 L | 2000 L
2250 L - 4000 L | 4000 L
4250 L - 6000 L | 5000 L
5250 L - 8000 L | 6000 L
6250 L - 10000 L |
| Material | Steel (Standard) or Aluminium (Optional) or HDPE (Optional) | | | | |
| Dump Door | Fixed Tank with Manhole Opening (Standard) Hydraulic dump - 36” or Fully opening rear door (Optional) | | | | |
| Sight Glass | Primary 1 x Rear door (Standard) - Secondary (Optional) | | | | |
| Coating | Exterior Coating (Standard) - Internal Coating (Optional) | | | | |
| Valve Connection | 2 x Manual Operated Discharge / Suction Camlock (Standard) | | | | |
| Safety | 1 x Pressure Release Valve (Standard) - Vacuum Relief Valve (Optional) | | | | |
| Transfer Pump | Optional | | | | |
| | | | | |
| Water System | | | | | |
| High Pressure Washer Pump | 150 bar (Optional) | 240 bar (Optional) | | | | |
| Pump Flow | 15 lt/min (Optional) - 24 lt/min (Optional) | | | | |
| Tank Material | PE (Standard) - Steel (Optional) - Aluminium (Optional) | | | | |
| Tank Capacity | 100 lt / 250 lt / 500 lt / 1000 lt (Optional) | | | | |
| Heater | Use it for cleaning oil spills, frozen ground, and clay. (Optional) | | | | |
| Hose Reel | Optional | | | | |
| | | | | |
| Filtration System | | | | | |
| Shut off Valve | Primary Liquid level float ball (Standard) - Secondary Shut off valve (Optional) | | | | |
| Cyclone Valve | Primary Cyclone Filter (Standard) - Secondary Cyclone Filter (Optional) | | | | |
| Mud Filter | 1 x Mud Box (Standard) | | | | |
| Water Injection Collar | Dampening for dust or dusty materials (Optional) | | | | |
| Bag House Filter | Washable Polyester (Optional) - Polypropylene (Optional) - HEPA (Optional) | | | | |
| Bag Filter Cleaner | Automatic or Semi Automatic Pulse + Vibration Technology (Optional) | | | | |
| Oil Skimmer Package | Drum Oil Skimmer (Optional) | Shallow Water Suction Oil Skimmer (Optional) | | | | |
| Oil Transfer Pump | Optional | | | | |
| | | | | |
| Trailer | | | | | |
| Tires | Highway use with easy lube hubs | | | | |
| Axle | 2 axles | | | | |
| Material | Heavy duty tubular steel welded trailer | | | | |
| Surge Brake | Surge brakes for highway or off-road towing. (Optional) | | | | |
| Axle With Brake | Optional | | | | |
| Rubber Track | All terrain conditions - Rubber Truck package (Optional) | | | | |
| Anti Static | Anti Static Earth Belt system (Optional) | | | | |
| Atex Zone | PED, ADR (CEOC) and or ATEX (Optional) | | | | |
| Road Light | Optional | | | | |
| | | | | |
| Boom Package | | | | | |
| Boom Hose | 2" or 3" | 3" or 4" | 3" or 4" | 6" or 8" | 6" or 8" |
| Capacity | Rotate 270 degree extend to 4.3 mt (Standard) Rotate 270 degree extend up to 16,5 mt (Optional) | | | | |
| Boom operation | Manual rotation with hydraulic up & down (Standard) - Remote Control (Optional) | | | | |
| | | | | |
| Electrics | | | | | |
| All electrical connections sealed and water proofed. | | | | |
| Electrical System | 12v | 12v | 12v | 12v | 12v |
| | | | | |
| Ancillary Items | | | | | |
| | | | | |
| Ancillary items | Drum repair putty, dispersant / degreaser, safety torch & barrier tape. (Optional) | | | | |
| Disposal items | Disposal bags, Hazspill drum / waste receptacle, rope. Spill berm / bund and Mini mobile Incinerator. (Optional) | | | | |
| PPE-items | Chemical gloves, disposable overalls, coveralls, dust and chemical masks, goggles & safety glasses, portable eyewash units and First aid kits (Optional) | | | | |
