The Mavi Deniz Hydraulic Power Pack is engine-driven to convert a primary drive source into a hydraulic fluid flow for supplying the hydraulic power required. The hydraulic Powerpack can use boom reels, winches, skimmers, pumps, and powering various construction tools.

Pressure control valves limit or control the hydraulic pressure within the hydraulic system. Directional Control hydraulic valves: manual, electrical, pneumatic, or hydraulic operated valves direct the oil flow around the system to operate actuators, motors, or other functions.

Hydraulic Power Pack has the European standard EN 1834-1:2000 covering diesel engine operation in Zone 1 or Zone 2 hazardous areas where flammable gas or vapor may exist.

Hydraulic Power Pack comes in a wide range of power ratings and is made portable with an open frame on wheels, with a closed structure, bespoke power pack, skid frame power pack, containerized power pack, trailer mounted power pack.

The Mavi Deniz Power Packs are made using the best components available, guaranteeing a long lifetime with worldwide service and spare parts delivery at short notice. Hydraulic Power Pack designed and made in Turkey.

Features | Options

  • The wide range of power options
  • Single or dual control circuits
  • Compact, Low Noise & environmentally friendly.
  • Easy maintenance
  • Ergonomic control panel
  • Pure corrosion-resistant brass quick connect fittings.
  • Local or Remote Operations, via Wireless Controller
  • Attractive powder-coated finish
  • Heavy-duty wheels for easy transport
  • Build with world-class components.
  • Diesel | Gasoline | Gas | Hybrid
  • Standard | Portable | Trailer | Skid Mounted
PowerWeightEngine Type Flow & PressureReservoir
PP 5 4.8 hp 75 kgTier 3-4 Air Cooled Diesel13 L/min & 120 bar15 lt
PP 7 7 hp100 kgTier 3-4 Air Cooled Diesel19 L/min & 120 bar20 lt
PP 10 10 hp125 kgTier 3-4 Air Cooled Diesel27 L/min & 250 bar25 lt
PP 15 15 hp195 kgTier 3-4 Air Cooled Diesel35 L/min & 250 bar30 lt
PP 20 20 hp215 kgTier 3-4 Liquid Cooled Diesel40 L/min & 250 bar95 lt
PP 2525 Hp325 kgTier 3-4 Liquid Cooled Diesel55 L/min & 250 bar55 lt
PP 5050 hp386 kgTier 3-4 Liquid Cooled Diesel140 L/min & 250 bar90 lt
PP 80 80 hp523 kgTier 3-4 Liquid Cooled Diesel150 L/min & 250 bar160 lt
PP 120 120 hp850 kgTier 3-4 Liquid Cooled Diesel180 L/min & 250 bar200 lt
PP 150150 hp900 kgTier 3-4 Liquid Cooled Diesel200 L/min & 250 bar225 lt
PP 200200 hp950 kgTier 3-4 Liquid Cooled Diesel250 L/min & 250 bar250 lt
PP 225 225 hp950 kgTier 3-4 Liquid Cooled Diesel280 L/min & 250 bar275 lt
PP 250250 hp1050 kgTier 3-4 Liquid Cooled Diesel350 L/min & 250 bar300 lt
OptionalStandard | Portable | Trailer | Skid Mounted
Diesel | Gasoline | Ex Proof
