MAVI DENIZ manufactures spill containment berm that comes in any size you want. We have a Spill berm for one-gallon drums to primarily sized berms beneath tanker trucks or roll-off containers. We have three types of spill berms;

1) Small & Portable – Made for drums and small containers. This spill containment berm has flexible sidewalls making them easy to deploy and store. Compact, lightweight, and durable. The berm has flexible sidewalls making them easy to deploy and store—Compact, light, and durable.
2) Assembly Required – The L-bracket berm is the most economical one we sell. Assembly is easy and quick. Custom sizes available.
3) No Assembly – You lay this berm out and place your equipment on the berm. One type has snapped upsides, and two sides rise automatically to form a catch basin if there is a spill. Custom sizes are possible for Spill Containment Berm.

1) Small & Portable collapsible decontamination bund
It features a unique snap-lock solution that lets operators quickly create a safe and secure area to house drums, tanks, plants, and machinery or deal with potential spillage. Ideal for emergencies, temporary needs, and use for short-term projects. Ideal for labs and construction sites. Capturing leaks under trucks and other vehicles on site. Spill Berm Containment for fuel transfers from the tank to the vehicle. Lightweight and very easy to set up. Each model folds up so you can place it on a shelf. It frees up floor space when not in use. These collapsible decontamination bunds are especially suitable for hazardous material storage, emergency showers, pumping stations, body wash, or eyewash stations to capture the run-off of any contaminants.

  • Use these collapsible bunds as a decontamination area to capture waste or wash water.
  • Reusable
  • A spill containment berm is Ideal for construction sites or short-term needs.
  • Easy setup and fold up.
  • Chemical and rust-resistant
  • Foam or supported sidewalls. Only stand the wall up vertically.
  • Internal support braces are ideal for windy or more rugged conditions.
  • Collapsible decontamination bunds are easy to carry and compact to transport.
  • The berm is supplied in a carry bag.
  • The berm is made from standard duty (750gsm) PVC.

Safely storing, handling, and transporting drums, IBC tanks, generators, batteries, compressors, and machinery parts in the workplace are essential to protect workers and the environment from accidental spills, leaks, and drips.

Also available are heavy-duty PVC (1350gsm), chemical-duty XR5 (for additional chemical or abrasion resistance), and other specialized materials for more excellent durability. Track mat and ground mat options are available.

Track mats are used on top of the berm floor to frequently move equipment in and out. Ground mats are used under the berm floor if you are using them on dirt or gravel. A ground mat is unnecessary if the berm is used on asphalt or concrete. Berm floor if you are using it on dirt or gravel. A ground mat is unnecessary if the berm is used on asphalt or concrete.

Capacity (L)Dimension (M)Weight (KG)
Berm P15150.6 x 0.6 x 0.154
Berm P60601.2 x 1.2 x 0.158
Berm P75751.2 x 1.8 x 0.1510

2) Assembly Required spill berm

This spill berm provides an economical and efficient means of containment. By utilizing exterior “L” bracket supports, you get a sturdy sidewall that offers excellent containment. This portable berm provides 100% usable interior space. Set up is easy and can be done in most areas. Spill Containment Berm Conforms to federal and military regulations. The material is ripped, tear, punctured, and chemical resistant. The polyethylene material is appropriate for petroleum-based liquids, fuel, water, chemicals, etc. Space. Set up is easy and can be done in most areas: rip, tear, puncture, and chemical resistance. The polyethylene material is appropriate for petroleum-based liquids, fuel, water, chemicals, etc.

  • Use these spill berms as a decontamination area to capture oily waste, chemicals, or wash water.
  • Economical Secondary Spill Containment Berm for any equipment or vehicles.
  • The setup is easy.
  • It can be cleaned and stored for repeated use.
  • Chemical and UV resistant
  • Foam standard or optionally supported sidewalls. “L” Bracket Side Wall Supports.
  • It is made from standard duty (900gsm) PVC.

Also available are heavy-duty PVC (1350gsm), chemical-duty XR5 (for additional chemical or abrasion resistance), and other specialized materials for more excellent durability. Track mat and ground mat options are available.

Optional Ground Mat and Track Mat (Protection from Tire Tread) are possible upon request. Track mats are used on top of the berm floor to frequently move equipment in and out. Ground mats are used under the berm floor if you are using them on dirt or gravel. A ground mat is unnecessary if the spill berm is used on asphalt or concrete. Berm floor if you are using it on dirt or gravel. A ground mat is redundant if the berm is used on asphalt or concrete.

Do You Need An Optional Ground Mat or Track Mat For Your Berm?

You can order an option, a ground mat, or a track mat for your berm. Ground mats are placed under the spill berm on the ground as an additional layer of protection for the berm floor. If you are putting the berm on dirt or gravel, purchasing a ground mat is a good idea to prevent rocks or sticks from working through the floor of your spill berm. A ground mat is generally unnecessary on concrete or asphalt if the containment berm is used.

A track mat is a thick rubber material placed on the top side of the berm floor. Purchasing this option is a sound investment if you drive vehicles or equipment in and out of the spill containment berm daily or weekly. The Spill Berm Is thick rubber material placed on the top side of the floor of the berm. Purchasing this option is a sound investment if you drive vehicles or equipment in and out of the spill containment berm daily or weekly.

Capacity (L)Dimension (M)Weight (KG)
Berm L0,60.61.2 x 1.8 x 0.310
Berm L2,82.81.8 x 1.8 x 0.315
Berm L20203.0 x 3.0 x 0.325
Berm L21214.6 x 15 x 0.3120
Berm L28284.6 x 20 x 0.3150

3) No Assembly spill berm

This spill berm is the fastest and easiest spill containment berm on the market. No assembly is needed. It merely needs to be unfolded, and it is ready for use. Sidewall construction allows the walls to remain flat so they can be entered or exited from any side! The walls will rise automatically when filled with fluid. There are no side walls to put up or hinges to break manually. This secondary spill containment berm is sturdy and can quickly be deployed from location to location throughout the day.

You lay these berms out and place your equipment on the berm. One type has snapped upsides, and two sides rise automatically to form a catch basin if there is a spill. The walls rise automatically when filled with liquid.

It allows for hands-free drive-in and out access without the risk of tearing the corners. In the event of a spill, the walls will rise automatically as the berm fills up.

Available options include ground tarps and track mats. Ground tarps are usually purchased if the berm is in dirt or gravel. Track mats are purchased if the equipment is driven in and out frequently. Include ground tarps and track mats. Ground tarps are usually purchased if the berm is in dirt or gravel. Track mats are purchased if the equipment is driven in and out frequently.

  • Use these spill berms as a decontamination area to capture oily waste, chemicals, or wash water.
  • Economical Secondary Spill Containment Berm for any equipment or vehicles.
  • Just Unfold, Drive In, Drive Out, Fold Up
  • Hand-Free Drive-In and Drive Out
  • It can be cleaned and stored for repeated use.
  • Chemical and UV resistant
  • Walls automatically rise when filled with fluid.
  • No assembly is required.
  • The walls lay flat.
  • Setup takes less than 1 minute.
  • They can be driven on at any angle.
  • Soft foam sidewall easily compresses for convenient loading and off-loading.
  • It is made from heavy-duty PU fabric for water, hydrocarbons, and most chemicals.
Capacity (L)Dimension (M)Weight (KG)
Berm 2202201.2 x 1.8 x 0.120
Berm 6006002.4 x 2.4 x 0.140
Berm 9409403.0 x 3.0 x 0.150
Berm 188018803.0 x 6.0 x 0.185
Berm 283028303.0 x 9.0 x 0.1115
Berm 377537753.0 x 12 x 0.1150
Berm 471547153.0 x 15 x 0.1180
Berm 136013603.7 x 3.7 x 0.170
Berm 226522653.7 x 6.0 x 0.190
Berm 340034003.7 x 9.0 x 0.1108
Berm 450045003.7 x 12 x 0.1160
Berm 560056003.7 x 15 x 0.1200
Berm 679567953.7 x 18 x 0.1230
Berm 810081003.7 x 22 x 0.1270
Berm 212521254.6 x 4.6 x 0.190
Berm 284028404.6 x 6.0 x 0.1110
Berm 425042504.6 x 9.0 x 0.1150
Berm 565056504.6 x 12 x 0.1190
Berm 708070804.6 x 15 x 0.1230
Berm 10190101904.6 x 22 x 0.1370
